A simple layer pad.
Can be used to separate sections internally within a box or used for base protection or layer separation.
All dimensions are expressed as internal dimensions in mm as follows:
Length (L) x Width (W) x Height (H)
:
Longer dimension at the opening
:
Shorter dimension at the opening
:
Dimension from the top of the opening to the base
:
A variable dimension defined by the design attributes
The dimensions L, W, H and v are specified in each description of the case construction, for some designs the numerical value of W can exceed the numerical value of L.
Dimensions should be measured on the flat blank from the centre of crease bearing the thickness of the material in mind.
For telescope-type boxes:
The height (h) of the upper part (lid) should be given as a fourth measurement after an oblique stroke.
For cases with overlapping outer flaps:
For cases with overlapping outer flaps:
The length of the area of overlapping (o) should be given as a fourth measurement after an oblique stroke.
For cases with overlapping outer flaps:
=
usually manual erection
=
usually automated erection
=
can be either manual or automated
=
requires a combination of both
=
cutting forme required
